How Operation Pneumatic wire stripping machine WPM-3F, 1. This machine is special for stripping the special wires in the field of harness industry, such as computer core wires, shield wires, phone lines, flat cables and such smaller wires, the general size of wires is AWG18-32#, the wires which with diameter of more than 0.5mm all can be processed with this machine.

How operation Full-automatic Computer Multiple Core Round Sheath Wire Stripping Machine, This machine is suitable for the processing of multiple core round sheathing lines. Various processes such as cutting, stripping, and core stripping can be completed at one time.

How to operate Automatic tube cutting winding and tying machine, 1.1. Winding mechanism: Adjust the winding column back and forth to the size required by production, 1.2. Loading mechanism: Adjust the wire clip before and after the winding mechanism winding clip, 1.3. Meter metering mechanism of wiring: adjust the wire wheel, wire clip, wire pressing mechanism, and meter mechanism to the appropriate pressure of the production wire, and adjust the wire clip in the center of the cutting tool before

How to operate Terminal Crimping Machine OPERATING INSTRUCTION, 1. To set up in the stable or no vibration ground or table should be in a space radiate well, 2. Basic power to 220AC electricity, and use the machine with a dedicated power plug,3. Use the dedicated wall outlet, and make sure that the proper operating temperature (is 0-40 degrees Celsius).

Tape wrapping machine WPM-303 User Manual, The second-generation tape-wrapping machine, Click the screen to select full wrapping, point wrapping, and multi-segment wrapping according to wrapping mode, Select “Full wrapping”, tread on the foot pedal to start operating, and press “Wheel closure switch”, the machine operates at full speed and stops operation when the foot pedal is released.
